Product Details:
|
| Saw Blade: | Diameter 350mm And 300mm | Max Tenoning: | 100mm |
|---|---|---|---|
| Worktable Range: | 400*180mm | Milling Bits: | Vertail And Horizontal |
| Function: | Milling And Cutting | Suitable Material: | Window And Doors Alu Profiles |
| Highlight: | 350mm Aluminum End Milling Machine,350mm 5 Axis Horizontal Machining Center,0.5MPa 5 Axis Horizontal Machining Center |
||
2. The system adopts CNC control system, the CNC servo motor adjusts the tool to move up and down, left and right, the milling stroke is controllable, the feed speed is adjustable, and the tool retracts quickly. The processing range is large, the operation is convenient, and the production efficiency is high.
| Product Parameter | |
| Motor power | 2×3 kw |
| Power supply | 380V/50Hz (Can make according your voltage) |
| Air pressure | 0.5~0.8MPa |
| Motor rotary speed | 2800r/min |
| Saw blade specification | Φ300 ,Φ350 |
| Maximum tenon | 100mm |
| Processing width*height | 400mm*180mm |
| Overall dimension | 2600×1350×1650mm |
| Weight about | 1200kg |
1.Provide free training when come to factory study.
2. If need engineer go to oversea training: Client afford transportation and accommodation, Engineer salary is 100USD/Day.
Because of Covid-19, we provide:
1. Before delivery: Machine operate manual, program software user manual and English videos.
2. Before delivery: Face to face video training online between your operator and our engineer.
3. After delivery: Will video guild you how to install and adjust machine. Also we can online control your machine to show you how to work.
Machine Operate Manual Will Be Provided
Machine Operate Video Will Be Provided
1. What's the delivery time for machines?
Our delivery time is 15 days after getting deposit, customized machines should confirm with our sales persons.
2.What we can do if your machines have problems?
1).24 hours on line service each day, free technical support.
2) We can send you free components to you if your machines are in guarantee time.
3) We can send our engineers to repair your machines
3.Can you provide machine operation training?
1) Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training. All of our engineers have passport.
2)Machine Operate Manual Will Be Provided .Machine Operate Video Will Be Provided
